Τεχνικά Χαρακτηριστικά:
Camera
Image Sensor 1/2.8″ CMOS
Pixel 4 MP
Max. Resolution 2560 (H) × 1440 (V)
ROM 128 MB
RAM 256 MB
Electronic Shutter Speed 1/3s–1/30,000s
Scanning System Progressive
Min. Illumination Color: 0.05 lux@F1.6
B/W: 0.005 lux@F1.6
0 lux@F1.6 (Illuminator on)
Illumination Distance 30 m (98.43 ft) (IR)
30 m (98.43 ft) (white light)
Illuminator On/Off Control Manual; Smart IR; Off
Illuminator Number 2 (IR)
2 (white light)
PIR Sensor Distance 10 m (the height of device is 2.2 m, placed horizontally,+25°C,+77°F)
7m (the height of the device is 2.2 m, placed at an angle of 15° from the horizontal,+25°C,+77°F)
Battery
Battery Type Lithium-ion
Capacity 10 Ah
Max. Charging Voltage 4.2 V
Operating Temperature 0 °C to +50 °C (+32 °F to +122 °F)
Battery Voltage 3.6 V
Cycle Lifetime Sleep Mode:7 days (at the rate of 1-hour remote live view per day)
Battery Life More than 500 cycles
Battery Weight Approx. 192 g (0.42 lb)
Solar Module
Maximum Power 5.5 W
Cell type Monocrystalline
Operating Temperature –40 °C to +80 °C (–40 °F to +176 °F)
Dimensions 224 mm × 195 mm × 44 mm (8.8″ × 5.9″ × 1.7″) (L × W × H)
Standard testing condition AM = 1.5, 25 °C (77 °F), 1000 W/m², SMQ + 12%
Lens
Focal Length 4mm
Max. Aperture F1.6
Field of View H: 84°
V: 42°
D: 101°
Close Focus Distance 2 m (6.56 ft)
Iris Control Fixed Iris
DORI Distance Detect Observe Recognize Identify
86 m (282.15 ft)
34.4 m (112.86 ft)
17.2 m (56.43 ft）
8.6 m (28.22 ft)
PTZ
Pan/Tilt Range Pan: 0° to 345°
Tilt: 0° to +80°
Manual Control Speed Pan: 0.1°/s–74°/s
Tilt: 0.1°/s–36.4°/s
Preset Speed Pan: 62°/s; Tilt: 36.3°/s
Preset 300
Power-off Memory Yes
Idle Motion Preset
Active Deterrence
Light Warning White light warning
Flash duration: 5 s–30 s
Flash frequency: High, medium, low
Sound Warning 1 sound warning alarm
The alarm can be configured to go off 1-3 times
Video
Video Compression H.265; H.264; H.264B; H.264H; MJPEG(Sub Stream)
Streaming Capability 2 streams
Resolution 4M (2560 × 1440); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280×720); D1 (704 × 576); CIF (352 × 288); VGA (640 × 480)
Video Frame Rate
Main stream: 4M/1080p/1.3M/720p @ (1–25/30 fps)
Sub stream 1: D1/CIF/VGA@ (1–25/30 fps)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32 kbps–8192 kbps
Day/Night Auto (ICR)
BLC Yes
WDR DWDR
HLC Yes
White Balance Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp
Gain Control Auto; manual
Noise Reduction 2D NR; 3D NR
Motion Detection Yes
Region of Interest (RoI) Yes
Defog Electronic
Image Rotation 180°
S/N Ratio ≥ 55 dB
Audio
Audio Compression G.711a; G.711Mu; G.726; PCM
Network
Network Port RJ-45 (10/100 Base-T)
4G Yes
Frequency Band
LTE-FDD: B1/3/5/7/8/20/28
LTE-TDD: Band 38/40/41
WCDMA: Band 1/5/8
GSM: 850/900/1800 MHz
Network Protocol HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; Qos; FTP; UPnP; ICMP; SNMP; IGMP; ARP; RTCP; RTP; PPPoE; RTMP; Bonjour; SMB; NFS
Interoperability ONVIF (Profile S&G&T);CGI;SDK;P2P
Streaming Method Unicast/Multicast
User/Host 20 (total bandwidth: 64 M)
Storage FTP; Micro SD card (support up to 512 GB); NAS
Browser IE 9 and later versions
Chrome 41 and earlier versions
Firefox 50 and earlier versions
iOS 10 and later versions
Management Software DMSS
Mobile Client iOS; Android
Certification
Certifications CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
CE-RED: Radio Equipment Directive 2014/53/EU;
FCC: 47 CFR FCC Part 15; Subpart B
Port
Audio Input 1 channel (built-in mic)
Audio Output 1 channel (built-in speaker)
Alarm Linkage Capture; record; send email; preset; audio; warning light
Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; passive infrared detection
Power
Power Supply 5.4 VDC, 3A (Standard solar panel)
Battery Life on a Full Charge Sleep Mode: 7days (at the rate of 1-hour remote live view per day)
Power Consumption Sleep: 35 mW
Static: 2.3 W (daytime,only SD storage) 2.5 W (daytime: pulling stream in 4G), 4.8 W (illuminator on, pulling stream in 4G)
Max.: 10 W (illuminator + PTZ + heater + pulling stream in 4G)
Environment
Operating Temperature 0 °C to +50 °C
Operating Humidity ≤ 95%
Storage Temperature 0 °C to +50 °C
Storage Humidity ≤ 95%
Protection IP66 TVS 2000 V lightning proof; surge protection; voltage transient protection
Structure
Product Dimensions 336 mm × 247 mm × 223 mm (L × W × H)
Net Weight 1.40 kg
Gross Weight 2.14 kg
