Τεχνικά Χαρακτηριστικά:
Camera
Image Sensor
1/2.8″ CMOS
Pixel
5MP
Max. Resolution
2560 (H) × 1920 (V)
ROM
128 MB
RAM
128 MB
Electronic Shutter Speed
1/3 s–1/100,000 s
Scanning System
Progressive
Min. Illumination
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (illuminator on)
Illumination Distance
30 m (98.42 ft) (IR)
30 m (98.42 ft) (white light)
Illuminator On/Off Control
Manual; auto; off
Illuminator Number
2 (IR light)
2 (White light)
Lens
Focal Length
4 mm
Max. Aperture
F1.6
Field of View
H: 80.4° V: 58.1° D: 104.8°
Close Focus Distance
0.3 m (0.98 ft)
Iris Control
Fixed
DORI Distance
Detect
Observe
Recognize
Identify
77.4 m (253.94 ft)
31.0 m (101.71 ft)
15.5 m (50.85 ft)
7.74 m (25.39 ft)
PTZ
Pan/Tilt Range
Pan: 0° to 345°
Tilt: 0° to +80°
Manual Control Speed
Pan: 0.1°–74°/s
Tilt: 0.1°–36.4°/s
Preset Speed
Pan: 62°/s
Tilt: 36.3°/s
Preset
300.0
Power-off Memory
Yes
Idle Motion
Preset
Smart Event
IVS
Tripwire; intrusion
Human Detection
Yes
Active Deterrence
Light Warning
White light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low
Sound Warning
Sound warning alarm: Customizable Alarm duration: 10 s, 20 s, 30 s
Video
Video Compression
H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+
Streaming Capability
2 streams
Resolution
5M (2560 × 1920); 4M (2560 × 1440); 1080p (1920 × 1080); 960p(1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
Video Frame Rate
Main stream: 5M(1–20 fps), 4M/1080p/1.3M/720p (1–25/30 fps)
Sub stream: D1/CIF (1–25/30 fps)
Bit Rate Control
CBR/VBR
Video Bit Rate
H264: 512–8192 kbps
H265: 233–7680 kbps
Day/Night
Auto (ICR)/Color/B/W
BLC
Yes
WDR
DWDR
HLC
Yes
White Balance
Auto; manual; tracking; indoor; outdoor; sodium lamp; street lamp; natural light
Gain Control
Auto; manual
Noise Reduction
2D NR; 3D NR
Motion Detection
Yes
Image Rotation
180°
S/N Ratio
≥ 55 dB
Audio
Audio Compression
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1
Network
Network Port
RJ-45 (10/100 Base-T)
Network Protocol
UDP; FTP; RTMP; IPv6; IPv4; IP Filter; DNS; RTCP; HTTP; NTP; SSL; DHCP; RTP; SMTP; HTTPS; TCP/IP; RTSP; DDNS; ARP
Interoperability
CGI; SDK; ONVIF (Profile S&T); P2P
Streaming Method
Unicast/Multicast
User/Host
20
Storage
Micro SD card (512 GB); FTP
Browser
IE: IE 7 and later versions; Chrome; Firefox; Safari
Management Software
DMSS
Mobile Client
iOS; Android
Certification
Certifications
CE: EN55032/EN50130-4/EN IEC61000-3-3/EN IEC61000-3-2/EN55024/EN55035/EN62368-1
FCC: 47 CFR FCC Part15, Subpart B, ANSI C63.4:2014
Port
Audio Input
1 channel (built-in mic)
Audio Output
1 channel (built-in speaker)
Two-way Audio
Yes
Alarm Linkage
Capture; preset; recording; audio; sending email
Alarm Event
Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
Audio I/O
1/1
Power
Power Supply
12 VDC/1.5 A ± 10% PoE (802.3af)
Power Consumption
Basic: 4 W
Max.: 12.95 W (illuminator + PT + speaker + heating glass)
Environment
Operating Temperature
–30 °C to +55 °C (–22 °F to +131 °F)
Operating Humidity
≤ 95%
Protection
IP66; TVS 2000 V lightning proof; surge protection;
voltage transient protection
Structure
Product Dimensions
140.5 mm × Φ111.0 mm (5.53″ × Φ4.45″)
Net Weight
0.5 kg (1.10 lb)
Gross Weight
1 kg (2.20 lb)
The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model.
